Motorized Panel Track

Motorized Panel Track

A great solution for sliding doors, larger windows and room dividers.


  1. The panel track is the ideal way to cover large windows or sliding doors. They also work as well as a room divider.
  2. The panel allows you to keep your view while blocking the glare and much of the harmful UV rays.
  3. Strong elegant appearance.
  4. Durable screw rod to drive. Overloading protection.
  5. Simple connectivity, programming and operation.
  6. One touch for controlling the individual or groups of tracks.
  7. Able to be integrated with home automation system.
  8. Built-in dry contact closure interface for direct connection to Automation or Smart Home System.
  9. Designed with reliability and safety – 24V DC transformer.

Motorized panel tracks block out most light and UV and provide the excellent privacy. Motorized panel tracks offer function and the freedom to create inspired designs for windows, doors and room dividers.

Working VoltageDC 24V, 1A
Radio Frequency433.92 MHz, ASK
Load Capacity20kgs
Track Pass3,4, and 5 pass
Track Length5.4m (maximum)
Range of Remote Control30 m
PowerAC 100-240V, 50-60Hz
