Motorized Drapes – Belt Driven

Motorized Drapes – Belt Driven

Humanized design and unique functions.


  1. Durable belt to drive. it offers quiet, smooth and reliable operation.
  2. With clutch function, it can manually control the curtains when power failure.
  3. Adopting the Japanese dyneema strap and Japanese clutch.
  4. Opening Direction: One way draw or center opening.
  5. Simple connectivity, programming and operation.
  6. Motor can be oriented on either side of window or space.
  7. Integrated with home automation system.
  8. Built-in dry contact closure interface for direct connection to Automation
    or Smart Home System.
  9. Designed with Reliability and Safety – 24V DC transformer.

Motorized drapes offer great versatility. It can suit for most of decor requiring a functional and elegant window treatment solution. The innovative technology brings customers a reliable, affordable, and user friendly product, for home or business environments.

Technical Data:
Working VoltageDC 24V, 1A
Radio Frequency433.92 MHz, ASK
Load Capacity40 kgs(maximun)
Track Length6 m(maximun)
Range of Remote Control30 m
PowerAC 100–240V, 50-60Hz
Working VoltageDC 24V, 1A
DirectionCentral or one way opening
