Motorized Curtain Track – Screw Rod Driven

Motorized Curtain Track – Screw Rod Driven

Fully Automated Electric Curtains.


  1. Durable aluminum screw rod to drive. Overloading protection.
  2. The track is elegant, safe, durable and affordable.
  3. Opening Direction: One way or central opening.
  4. Simple connectivity, programming and operation.
  5. One touch for controlling the individual or groups of curtains.
  6. Able to be integrated with home automation system.
  7. Built-in dry contact closure interface for direct connection to Automation
    or Smart Home System.
  8. Designed with reliability and safety – 24V DC transformer.

Motorized curtain tracks bring a completely new thinking to your interiors. The system gives you the freedom to control the curtain. For example, the windows are hard to reach or rooms are with several windows.

Technical Data:
Working VoltageDC 24V, 1A
Radio Frequency433.92 MHz, ASK
Load Capacity30 kgs(maximun)
Track Length5.4 m(maximun)
Range of Remote Control30 m
PowerAC 100–240V, 50-60Hz
Working VoltageDC 24V, 1A
DirectionCentral or one way opening
